Cat® 3516B Industrial Diesel Engine

  • Minimum Power
    2000.0 bhp
  • Maximum Power
    2200 HP
  • Maximum Power
    2200.0 bhp
  • Rated Speed
    1800 rpm
Power Rating
Minimum Power
2000.0 bhp
Maximum Power
2200 HP
Maximum Power
2200.0 bhp
Rated Speed
1800 rpm
Minimum Power
2000 HP
Rated Speed
1800 rpm
Emission Standards
Emissions
Non-Certified
Emissions
Non-Certified
General
Engine Configuration
V-16, 4-Stroke-Cycle Diesel
Engine Configuration
V-16, 4-Stroke-Cycle Diesel
Bore
170 mm (6.7 in)
Bore
170 mm (6.7 in)
Bore
6.7 in
Stroke
7.5 in
Stroke
190 mm (7.5 in)
Stroke
190 mm (7.5 in)
Displacement
4210 in³
Displacement
69 L (4210 in³)
Aspiration
Turbocharged Aftercooled
Displacement
69 L (4210 in³)
Aspiration
Turbocharged Aftercooled
Rotation
Counterclockwise
Rotation from Flywheel End
Counterclockwise
Aftertreatment
-
Engine Dimensions - Approximate
Length
119 in
Width
57 in
Height
78 in
Weight
16500 lb
Height
1980 mm (78 in)
Length
3008 mm (119 in)
Weight
7484 kg (16,500 lb)
Width
1443 mm (57 in)
Engine Dimensions (Approximate. Final dimensions dependent on selected options)
Length
3008 mm (119 in)
Width
1443 mm (57 in)
Height
1980 mm (78 in)
Weight
7484 kg (16,500 lb)
  • Air Inlet System
    • Aftercooler core, corrosion resistant coated (air side)
    • Air cleaner. Regular duty, dry, panel type with service indicators, turbocharger, jacket water aftercooled.
    • Turbocharger, rear mounted
    • Jacket water aftercooled
  • Control System
    • Governor, RH, 3161 with self contained synthetic oil sump
    • Air-fuel ratio control
    • Mechanical speed control, without torque control
    • Governor control
    • Positive locking
  • Cooling System
    • Thermostats and housing
    • Jacket water pump, centrifugal
  • Exhaust System
    • Exhaust manifold, dry
  • Flywheels and Flywheel Housing
    • SAE No. 00 flywheel
    • 183 flywheel teeth
    • SAE No. 00 flywheel housing
  • Fuel System
    • Fuel filter, with service indicators, cartridge type with RH service
    • Fuel transfer pump
  • Instrumentation
    • Instrument Panel, RH
    • Engine oil pressure gauge
    • Fuel pressure gauge
    • Oil filter differential gauge
    • Jacket water temperature gauge
    • Service meter, electric
    • Tachometer
  • Lube System
    • Crankcase breather, top mounted
    • Oil cooler
    • Oil filler
    • Oil dipstick
    • Oil pump
    • Oil filter, cartridge type with RH service
    • Shallow oil pan
  • Mounting System
    • Rails, mounting, engine length, 254 mm (10 in), industrial-type, C-channel.
  • Power Take Off
    • Accessory drive, upper RH
    • Front housing, single sided
  • Protection System
    • Junction box
    • Manual shutoff, RH
    • Safety shutoff protection, energized to shutdown
    • Low oil pressure, low idle 69 kPa (10 psi); high idle 207 kPa (30 psi)
    • Water temperature
    • Overspeed
    • 3161 governor solenoid energized to shutdown
  • Starting System
    • Starting switch
  • General
    • Vibration damper
    • Lifting eyes
    • Paint: Caterpillar yellow, with optional colors available at request
