Excavators

352F LRE Long Reach Excavation Hydraulic Excavator

  • Engine Model
    Cat® C13
  • Net Power
    408 HP
  • Operating Weight
    130955 lb
  • Swing Torque
    109528 ft·lbf
Engine
Engine Model
Cat® C13
Net Power
408 HP
Stroke
6.2 in
Bore
5.1 in
Displacement
763 in³
Power
317 kW (431 PS)
Power
304 kW (413 PS)
Gross Power
322 kW (438 PS)
Weights
Operating Weight
130955 lb
Maximum Weight
130955 lb
Swing Mechanism
Swing Torque
109528 ft·lbf
Swing Speed
8.7 r/min
Sound Performance
Operator Sound Pressure Level
69 dB(A)
Note
Hearing protection may be needed when operating with an open operator station and cab (when not properly maintained or doors/windows open) for extended periods or in a noisy environment.
Exterior Sound Power Level
106 dB(A)
Note
*as per European Union Directive 2000/14/EC as amended by 2005/88/EC
Hydraulic System
Maximum Flow
7.1 gal/min
Stick Cylinder
7.48 in
Maximum Flow
102 gal/min
Boom Cylinder
147.6 in
Maximum Flow
79 gal/min
Boom Cylinder
6.69 in
Maximum Pressure
5076 psi
B1 Bucket Cylinder
109.8 in
B1 Bucket Cylinder
4.72 in
Stick Cylinder
169.5 in
Maximum Pressure
598 psi
Maximum Pressure
5076 psi
Maximum Flow
11.9 gal/min
Maximum Flow
203 gal/min
Maximum Pressure
5511 psi
Maximum Pressure
3989 psi
Drive
Maximum Travel Speed
2.9 mile/h
Maximum Drawbar Pull
74187 lbf
Maximum Gradeability
30°/70%
Service Refill Capacities
Swing Drive
2.6 gal (US)
Fuel Tank Capacity
190 gal (US)
Final Drive
4 gal (US)
Hydraulic Tank Oil
108 gal (US)
Cooling System
13.2 gal (US)
Hydraulic System Oil
151 gal (US)
DEF Tank
10.8 gal (US)
Engine Oil
10 gal (US)
Standards
Cab
SAE J1356 FEB88, ISO 10262:1998
Brakes
ISO 10265:2008
DEF
ISO 22241:2006
Cab
ISO 12117-2:2008
Track
Number of Shoes
52 pieces
Number of Track Rollers
9 pieces
Number of Carrier Rollers
3 pieces
