Cat® C3.6 Industrial Diesel Engine

  • Minimum Power
    74 bhp
  • Maximum Power
    121 HP
  • Maximum Power
    134 bhp
  • Maximum Torque
    369 lb-ft @ 1500 rpm
Power Rating
Minimum Power
74 bhp
Maximum Power
121 HP
Maximum Power
134 bhp
Maximum Torque
369 lb-ft @ 1500 rpm
Rated Speed
2200-2400 rpm
Minimum Power
74 HP
Rated Speed
2200-2400 rpm
Emission Standards
Emissions
China Nonroad Stage III Emission Standards. U.S. EPA Tier 3 Nonroad Equivalent Emission Standards (Not Currently EPA Certified). EU Stage IIIA Nonroad Equivalent Emission Standards (Non-Current for EU).
Emissions
UN ECE R96 Stage IIIA, Brazil MAR-1
General
Engine Configuration
Inline 4, 4-Stroke-Cycle Diesel
Engine Configuration
Inline 4, 4-Stroke-Cycle Diesel
Bore
98 mm (3.9 in)
Bore
98 mm (3.9 in)
Bore
3.9 in
Stroke
4.7 in
Stroke
120 mm (4.7 in)
Stroke
120 mm (4.7 in)
Displacement
220 in³
Displacement
3.6 L (220 in³)
Aspiration
Turbocharged Aftercooled (TA)
Displacement
3.6 L (220 in³)
Compression Ratio
17.0:1
Compression Ratio
17.0:1
Aspiration
Turbocharged Aftercooled (TA)
Combustion System
Direct Injection
Combustion System
Direct Injection
Rotation
Counterclockwise
Rotation from Flywheel End
Counterclockwise
Aftertreatment
-
Lube System
4 L (1.06 qt)
Lube System
4 L (1.06 qt)
Engine Dimensions - Approximate
Length
26.3 in
Width
22.2 in
Height
31 in
Weight
840 lb
Height
787 mm (30.98 in)
Length
667 mm (26.3 in)
Weight
381 kg (840 lb)
Width
564 mm (22.2 in)
Engine Dimensions (Approximate. Final dimensions dependent on selected options)
Length
667 mm (26.3 in)
Width
569 mm (22.4 in)
Height
776 mm (30.6 in)
Weight
275 kg (606 lb)
  • Control System
    • Starter motor (12V or 24V)
    • Alternator (12V or 24V)
    • Electronic Control Unit (chassis mounted)
    • Engine control sensors and robust wiring harness
    • Data interface via CANbus J1939
  • Flywheels and Flywheel Housing
    • Flywheel housings - SAE 3 or SAE 4
    • Choice of flywheel to match industry common hydraulic pumps and transmissions
    • Side PTO with SAE A or SAE B interface
  • Fuel System
    • Fuel filter - preconnected but chassis mounted
    • With water sensor
  • Lube System
    • Lubricating oil filters
    • High incline oil pan - 35 degrees continuous in all directions
  • General
    • Cold start capability to -20° C (-4° F)
    • Paint: Caterpillar yellow, with optional colors available at request
