Asphalt Pavers

AP500

  • Paving Range with SE47 FM
    2.4 m - 5.9 m (8' - 19' 6")
  • Gross Power
    148 hp
  • Engine Power
    148 hp
  • Engine Model
    Cat C4.4
Dimensions
Paving Range with SE47 FM
2.4 m - 5.9 m (8' - 19' 6")
Paving Range with SE47 V
2.4 m - 6.1 m (8' - 20')
Truck Entry Height
21 in
Operating Length
19.25 ft
Operating Width
10.75 ft
Overall Height
11 ft
Transport Length
18.5 ft
Transport Width
8.5 ft
Transport Height
8.6 ft
Engine
Gross Power
148 hp
Engine Power
148 hp
Engine Model
Cat C4.4
Engine Model
Cat C4.4
Operating Specifications
Maximum Paving Speed
200 ft/min
Maximum Travel Speed
10 mile/h
Maximum Throughput Capacity
1100 ton(US)/h
Weights
Operating weight with SE47 FM
32012 lb
Operating weight with SE47 V
31772 lb
Shipping Weight
25311 lb
Service Refill Capacities
Fuel Tank
53 gal (US)
DEF Tank
5 gal (US)
Cooling System
6.3 gal (US)
Hydraulic Oil Tank
32 gal (US)
Washdown Spray Tank
8.5 gal (US)
  • Operating Environment
    • Dual operating stations
    • Steering guide
    • Ventilation system
  • Technology
    • Product Link™ Elite 643 (cellular)
  • Powertrain
    • Cat C4.4, four-cylinder
    • Cooling fan, variable speed
  • Electrical System
    • 1400 CCA battery
    • 150-amp alternator
    • 12-volt charging system
    • Automotive-type fuse system
    • Auto-reset breaker for material sensors
    • Battery, maintenance-free
    • Cat Electronic Technician (Cat ET)
  • Material Delivery
    • Auger extensions, 0.15 m (6")
    • Material feed sensors, contact
    • Push-roller, adjustable
  • Service and Maintenance
    • Hydraulic oil, Cat HYDO Advanced
    • Remote access drains
    • Remote flash
    • Service repair kits
    • Sampling ports for Scheduled Oil Sampling
    • Sight Gauges, engine coolant, hydraulic oil
  • Safety
    • Alarm, back-up
    • Horn, warning (front & rear)
    • Lights, LED Working
    • Mirror package
  • Operating Environment
    • Canopy
    • Deceleration pedal
    • Heated seat
    • Umbrella
    • Side shields
    • Windshield
  • Technology
    • Cat Grade Control
    • Basic Grade Control
    • Product Link™ Elite 683 Cellular/Satellite
  • Powertrain
    • All-wheel drive
    • Ballast - front weights
    • Radial drive Tires
    • Sand-rib drive tires
    • Front-wheel assist
  • Material Delivery
    • Auger extensions, 0.46 m (1.5')
    • Mainframe extensions, power
    • Mainframe extensions, manual
    • Material feed sensors, sonic
    • Truck hitch
    • Wash-down pump and reel
  • Safety
    • Lights, LED Roading
    • Warning beacon, LED
