Backhoe Loaders
430 Backhoe Loader
-
Net Power107 hp
-
Displacement220 in³
-
Net Torque Rise358 ft-lb
-
Power Rating Conditions10000 ft
Engine
- Net Power
- 107 hp
- Displacement
- 220 in³
- Net Torque Rise
- 358 ft-lb
- Power Rating Conditions
- 10000 ft
- Net Power Rating at 2
- 107 hp
- Net Power Rating at 2
- 107 hp
- Emissions
- Engine meets Tier 4 Final/Stage V emission standards.
- Net Torque Rise
- 40%
- Ratings at 2
- 115 hp
- Ratings at 2
- 118 hp
- Engine Model
- C3.6 86 kW (115 hp) Electronic Turbo Intercooled
- Dimensions
- 4.72 in
- Net Peak Power Rating
- 107 hp
- Dimensions
- 3.86 in
- Net Peak Power Rating
- 107 hp
Weights
- Operating Weight
- 24251 lb
- Cab
- 320 lb
- Ride Control
- 33 lb
- Air Conditioning
- 99 lb
- Note
- **Minimum weight configuration is the same as configuration above, however, excludes counterweight, hoe bucket, and operator.
- Operating Weight
- 24251 lb
- MP Bucket
- 1642 lb
- Operating Weight
- 18051 lb
- MP Bucket
- 2017 lb
- Note
- *Machine configuration: standard stick hoe, OROPS canopy, AWD powershift shift transmission, 0.96 m3 (1.25 yd3) GP (General Purpose) loader bucket, 610 mm (24 in) standard duty hoe bucket, front 340/80-18 and rear 500/70-24 tires, 460 kg (1,014 lb) counte
- All
- STD
- Operating Weight
- 16590 lb
- Loader QC
- 540 lb
- Auto
- STD
- Counterweights
- 1014 lb
- Extendible Stick
- 655 lb
- Counterweights
- 529 lb
- Counterweights
- 256 lb
Backhoe
- Dig Depth
- 15.1 ft
Transmission
- Power
- 18 mile/h
- Power Shift Transmission
- 17 mile/h
- Power
- 3.7 mile/h
- Power
- 26 mile/h
- Power
- 25 mile/h
- Power Shift Transmission
- 3.7 mile/h
- Power Shift Transmission
- 26 mile/h
- Power Shift Transmission
- 7.7 mile/h
- Power
- 17 mile/h
- Power
- 5.9 mile/h
- Power Shift Transmission
- 3.7 mile/h
- Power Shift Transmission
- 12 mile/h
- Power
- 3.7 mile/h
- Power Shift Transmission
- 5.9 mile/h
- Power
- 7.7 mile/h
- Power
- 12 mile/h
- Power
- 17 mile/h
- Power
- 8 mile/h
- Power
- 17 mile/h
- Power
- 7.7 mile/h
- Power
- 3.7 mile/h
- Power
- 5.9 mile/h
- Power
- 3.7 mile/h
- Power
- 17 mile/h
- Power
- 12 mile/h
- Power
- 26 mile/h
- Power
- 8 mile/h
- Note
- *Travel speeds of backhoe loader at full throttle, when equipped with 500/70-24 rear tires.
- Note
- **Limited by engine speed to 40 km/h (25 mph).
Axle Ratings
- Front Axle
- 51808 lb
- Rear Axle
- 22046 lb
- Front Axle
- 19841 lb
- Rear Axle
- 58422 lb
Hydraulic System
- Pump Type
- Variable-flow, Axial Piston
- System Pressure
- 3626 psi
- Pump Capacity at 2
- 49.4 gal/min
- Type
- Closed Center
- System Pressure
- 3626 psi
Steering
- Bore
- 2.6 in
- Stroke
- 4.2 in
- Turning Circle
- 35.25 ft
- Axle Oscillation
- 11°
- Power Steering
- Hydrostatic
- Turning Circle
- 26.92 ft
- Rod Diameter
- 1.6 in
- Type
- Front Wheel Steering
- Cylinder
- One Double-Acting
Service Refill Capacities
- Transmission
- 4.8 gal (US)
- Diesel Exhaust Fluid
- 5 gal (US)
- Transmission
- 5 gal (US)
- Front Axle
- 2.9 gal (US)
- Front Axle
- 0.2 gal (US)
- Transmission
- 4.8 gal (US)
- Engine Oil
- 2.4 gal (US)
- Rear Axle
- 0.4 gal (US)
- Cooling System with Air Conditioning
- 4.8 gal (US)
- Rear Axle
- 4.2 gal (US)
- Fuel Tank
- 42.3 gal (US)
- Hydraulic System
- 25.1 gal (US)
- Hydraulic Tank
- 11.1 gal (US)
Sustainability
- Recyclability
- 92%
-
STANDARD EQUIPMENT
- Adjustable auxiliary controls, backhoe loader
- Air cleaner
- Alarm, back-up
- Audible system fault alarm
- Automatic Engine Speed Control (AESC)
- Battery, maintenance-free, 850 CCA
- Battery disconnect switch
- Boom transport lock
- Brace, lift cylinder
- Brake, parking, Spring Applied Hydraulically Released (SAHR)
- Brakes, hydraulically boosted, oil disc, dual pedals, interlocking
- Bucket level indicator
- Canopy, ROPS/FOPS
- Cat cushion swing system
- Coat restraint
- Coolant/antifreeze, extended life
- Dome light (cab only)
- Diagnostic port for engine, machine and gauge cluster Electronic Control Modules
- Differential lock, loader joystick
- Drink holders, two
- Engine, Cat C3.6 ACERT (Direct Injection Turbocharged), meets Tier 4 Final/Stage V emission standards, Selective Catalytic Reduction, Diesel Oxidation Catalyst (DOC)
- Engine enclosure, sound suppression, removable side panels
- Face seals, O-ring
- Fan, suction and guard
- Fast reversing shuttle, all gears
- Fenders, rear
- Filters, spin-on: fuel, engine oil, transmission oil, water separator
- Filters, bowl and cartridge: hydraulic fluid
- Flashing hazards/signal lights
- Floor mat
- Fuel tank, fully enclosed
- Four wheel drive
- Four wheel drive shaft guard
- Fully hinged front grill for cooling package cleaning access
- Gauge cluster: coolant temperature, fuel level, torque converter temperature, DEF level
- Ground level fuel fill and DEF fill
- Halogen lights, working (2 front, 2 rear)
- High ambient cooling package
- Hood lock, inside cab
- Hydraulic hose, XT™
- Hydraulic oil cooler
- Hydraulic oil level sight gauge
- Hydraulic valves, loader 2 function
- Hydraulic valves, backhoe 4 function
- Hydraulics, load sensing with variable displacement piston pump
- Indicator lights: wait to start, water in fuel, engine warning, warning lamp, emissions module malfunction, low battery/charging system warning, high hydraulic oil temperature: LCD warnings: engine oil pressure, machine locked, service due, air filter blocked, high coolant temperature, auto idle shutdown, high torque converter temperature, hydraulic filter bypass
- Instrument panel lights
- Joystick controls: pilot operated, excavator-style with pattern changer
- Key start/stop system
- LCD operator display with soft key controls: engine speed, hour meter, gear/direction, battery voltage, hydraulic oil temperature, torque converter temperature, coolant temperature, trip totals (fuel and hours), lifetime totals (fuel and hours), operator settings (units, brightness, programmable hoe auxiliary flow), service mode diagnostics, maintenance intervals, ECM/system info
- Loader, self-leveling, return-to-dig and transmission disconnect switch
- Loader, single tilt
- Mirror, interior, rearview
- One-touch low idle
- Open circuit breather
- Pattern changer, in cab
- Power receptacle, 5 volt USB, 1 internal
- Power receptacle, 12 volt, 2 internal, 1 external
- Power steering, hydrostatic
- Product Link™, satellite, network manager
- Product Link, cellular, network manager
- Seat belt, retractable, 51 mm (2 in)
- Socket, two roof
- Stabilizer shoes, street
- Steering knob
- Seat, air suspension, vinyl cover, with armrest
- Stabilizers, EH Control, Auto-UP
- Starting system, glow plugs
- Steering column, tilting, telescopic
- Storage compartment, lockable
- Storage tray
- Stop and tail lights
- Swing transport lock
- Tires
- Toolbox, external, lockable
- Torque converter
- Throttle, hand and foot, electronic
- Transmission, 4 speed, powershift
- Transmission neutralizer switch
- Transport tie-downs
- Vandalism locks, four
- Warning horn, electric
-
OPTIONAL EQUIPMENT
- Auxiliary hydraulics, loader, adjustable flow
- Auxiliary hydraulics, rear, adjustable flow
- Battery, additional, 850 CCA
- Cab, deluxe
- Cold weather fuel (–30° C/–22° F)
- Cold weather package, including additional battery, engine block heater, radiator antifreeze, cold weather fuel (–30° C/–22° F) and mounting for an ether bottle
- Counterweights, 115 kg (255 lb), 240 kg (530 lb) or 460 kg (1,015 lb)
- Fenders, front with integral steps
- Guard, boom protection plate
- Guard, stabilizer, rock
- Hydraulic valves, loader with auxiliary thumb control (3rd valve for MP or Quick Coupler)
- Hydraulic valves, backhoe (5th and 6th function)
- Hydraulic lines, combined function auxiliary
- LED lights, working (2 front, 2 rear)
- Quick Coupler, hydraulic, dual lock
- Quick Coupler, manual, dual lock
- Quick Coupler, manual, pin lock
- Radio and CD player, Bluetooth®
- Ride Control
- Rotating beacon, magnetic mount
- Seat, air suspension, fabric with armrest
- Seat, air suspension, fabric with armrest, heated
- Seat belt, retractable, 75 mm (3 in)
- Security system, Bluetooth
- Security system, operator display
- Side mirrors, cab, external
- Single Tilt Loader Coupler, Integrated Tool Carrier (IT) Interface
- Stabilizer pads, reversible
- Stick, extendible
- Transmission, AutoShift with lock-up torque converter, 6 speed
- Vandalism protection, gauge cover
- Work Tool Attachments such as buckets, forks, material handling arms, augers, hammers, brooms, cold planers and vibratory plate compactors. See your Cat dealer for more information.
-
