Compactors

CP11 GC Vibratory Soil Compactor

  • Operating Weight
    25109 lb
  • Weight
    14084 lb
  • Compaction Width
    84 in
  • Gross Power
    122.9 HP
Weights
Operating Weight
25109 lb
Weight
14084 lb
Operating Weight
25109 lb
Operating Weight
24769 lb
Weight
14084 lb
Weight
13988 lb
Note
Operating weights are approximate and consider full fluids and 75 kg (165 lb) operator. Cab weights include heat and air conditioning.
Operating Specifications
Compaction Width
84 in
Ground Clearance
20.3 in
Curb Clearance
19.5 in
Turning Radius
12.7 ft
Travel Speed
6.8 mile/h
Engine
Gross Power
122.9 HP
Engine Power
121 HP
Net Power
112.2 HP
Net Power
111.2 HP
Note
Net power advertised is the power available at the engine flywheel when equipped with a fan at maximum speed, air cleaner, clean emissions module, and alternator.
Engine Model
Cat® C3.6
Emissions
U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V
Stroke
4.7 in
Bore
3.9 in
Dimensions
Drum Width
84 in
Height
9.8 ft
Drum Diameter
60.4 in
Optional Blade Height
27.1 in
Overall Length
21 ft
Overall Width
8.25 ft
Compaction Width
84 in
Overall Length
18.7 ft
Overall Width
7.5 ft
Maximum Height
9.8 ft
Drum Diameter
60.9 in
Wheel Base
9.8 ft
Vibratory System
Vibratory Frequency
30.5 Hz (1830 vpm)
Variable Frequency Option Range
23.3 - 30.5 Hz (1400-1830 vpm)
Nominal Amplitude
0.071 in
Nominal Amplitude
0.035 in
Centrifugal Force
55932 lb
Centrifugal Force
33249 lb
Tires
Tires
23.1 x 26
Service Refill Capacities
Fuel Tank Capacity
56.3 gal (US)
DEF Tank
5 gal (US)
Cooling System
4.9 gal (US)
Engine Oil
3.1 gal (US)
Eccentric Weight Housings
6.9 gal (US)
Axle and Final Drives
2.6 gal (US)
Hydraulic Tank
6.1 gal (US)
Sustainability
Recyclability
97%
  • NOTE
    • Standard and optional equipment may vary. Consult your Cat dealer for details.
  • OPERATOR ENVIRONMENT
    • ROPS/FOPS Canopy with Handrails, Floor Mat, Interior Rear View Mirror
    • Vinyl Suspension Seat
    • Adjustable Tilting Steering Column
    • High Visibility 76 mm (3 in) Seat Belt
    • 12-volt Power Outlet
    • Horn, Backup Alarm
  • VIBRATORY SYSTEM
    • Padfoot Drum - Oval or Square Pads
    • Pod-Style Eccentric Weight Housings
    • Dual Amplitude, Dual Frequency
    • Auto-vibe Function
    • Dual Adjustable Steel Scrapers
  • TECHNOLOGY SOLUTIONS
    • VisionLink®
    • Remote Flash
    • Remote Troubleshoot
    • Remote Disable
  • POWERTRAIN
    • Cat® C3.6 Engine
    • Single Propel Pump
    • Fuel Filter, Water Separator, Priming Pump, Water Indicator
    • Radiator/Hydraulic Oil Cooler
    • Dual Braking System
    • Two-Speed Hydrostatic Transmission
    • Limited Slip Differential
  • ELECTRICAL
    • 12 volt Electrical System
    • 150 ampere Alternator
    • 900 Cold-cranking Amps Battery Capacity
    • Battery Disconnect Switch
  • OTHER
    • Sight Gauges for Hydraulic Oil Level and Radiator Coolant Level
    • S·O·S℠ Sampling Values: Engine Oil, Hydraulic Oil, and Coolant
    • Lug Tread Tires
    • Working Lights (2 Forward, 2 Rear)
  • NOTE
    • Standard and optional equipment may vary. Consult your Cat dealer for details.
  • OPERATOR ENVIRONMENT
    • ROPS/FOPS Cab with Climate Control, Floor Mat, Exterior Rear View Mirrors
    • Deluxe High-back Air-ride Seat (Cab)
    • Sun/Debris Shields (Canopy)
    • Roll-down Sun Screen (Cab)
    • Interior Rear View Mirror (Cab)
    • Exterior Rear View Mirrors (Canopy)
    • Rear View Camera with Color Touchscreen Display
    • Seat Belt Switch
    • Sound Reduction Kit
  • TECHNOLOGY SOLUTIONS
    • Measure - Machine Drive Power (MDP)
    • Machine Speed Sensor
  • POWERTRAIN
    • Transmission Guard
  • OTHER
    • High Ambient Temperature Oil Factory Fill
    • Upgraded Lighting Package (4 Forward, 4 Rear)
    • Amber Rotating Beacon
