Compactors

CP56B Vibratory Soil Compactor

  • Operating Weight with Cab
    25707.0 lb
  • Operating Weight
    25707 lb
  • Operating Weight with ROPS
    25264.0 lb
  • Weight at Drum with ROPS
    14026.0 lb
Weights
Operating Weight with Cab
25707.0 lb
Operating Weight
25707 lb
Operating Weight with ROPS
25264.0 lb
Weight at Drum with ROPS
14026.0 lb
Weight
14231 lb
Operating Weight
25264 lb
Weight
14026 lb
Operating Specifications
Compaction Width
84.0 in
Compaction Width
84 in
Ground Clearance
17.9 in
Travel Speed
7.0 mph
Turning Radius
12.08 ft
Ground Clearance
17.9 in
Travel Speed
7 mile/h
Engine
Gross Power
157.0 hp
Gross Power
157 hp
Engine Model
Cat C4.4 with ACERT
Engine Model
Cat C4.4 with ACERT
Dimensions
Drum Diameter
51.0 in
Drum Width
84.0 in
Overall Length
19.25 ft
Overall Width
7.58 ft
Wheelbase
9.58 ft
Drum Diameter
61 in
Height
10.25 ft
Optional Blade Height
27.1 in
Overall Length
21 ft
Overall Width
8.25 ft
Drum Diameter
51 in
Drum Width
84 in
Overall Length
19.25 ft
Overall Width
7.58 ft
Wheel Base
9.58 ft
Vibratory System
Nominal Amplitude
0.083 in
Nominal Amplitude
0.039 in
Variable Frequency Option Range
23.3 - 30.5 Hz (1400-1830 vpm)
Vibratory Frequency
30.5 Hz (1830 vpm)
Centrifugal Force
67600 lb
Centrifugal Force
31670 lb
Nominal Amplitude
0.083 in
Nominal Amplitude
0.039 in
Variable Frequency Option Range
23.3 - 30.5 Hz (1400-1830 vpm)
Vibratory Frequency
30.5 Hz (1830 vpm)
Tires
Tires
23.1 x 26
Tires
23.1 x 26
Service Refill Capacities
Fuel Tank Capacity
64.0 gal
Fuel Tank Capacity
64 gal (US)
  • OPERATOR ENVIRONMENT
    • ROPS/FOPS Canopy with Handrails/Guardrails, Floor Mat
    • Vinyl Adjustable Pivoting Seat with Integrated Console and LCD Display
    • Adjustable Tilting Steering Column with Integrated Cup Holders
    • Rear Vision Camera with Color Touchscreen Display
    • Seat Belt
    • 12-volt Power Outlet
  • VIBRATORY SYSTEM
    • Padfoot Drum
    • Dual Amplitude, Single Frequency
    • Dual Pod-Style Eccentric Weight Housings
    • Auto-vibe Function
    • Front Adjustable Steel Scraper
  • POWER TRAIN
    • Cat C4.4 Diesel Engine
    • Air Cleaner, Dual Element
    • Three-Speed Throttle Switch, Eco-mode and Automatic Speed Control
    • Dual Propel Pumps; One for Drum Drive, One for Rear Axle
    • Fuel Filter, Water Separator, Priming Pump, Water Indicator
    • Tilting Radiator/Hydraulic Oil Cooler
    • Dual Braking System
  • ELECTRICAL
    • 24 volt Electrical System
    • 100 ampere Alternator
    • 750 Cold-cranking Amps Battery Capacity
  • OTHER
    • Product Link
    • Sight Gauges for Hydraulic Oil Level and Radiator Coolant Level
    • SOS℠ Sampling Valves: Engine Oil, Hydraulic Oil and Coolant
  • OPERATOR ENVIRONMENT
    • ROPS/FOPS Cab with Climate Control, Cloth Seat
    • Internal Rear View Mirror
    • External Rear View Mirrors
    • Sun Visor
    • Cab Internal Roll-down Sun Screen
  • VIBRATORY SYSTEM
    • Leveling Blade
    • Variable Frequency
    • Dual Adjustable Steel Scrapers
  • POWER TRAIN
    • Transmission Guard
  • TECHNOLOGY SOLUTIONS
    • Measure - Machine Drive Power
    • Map - SBAS GNSS Mapping
    • Connect - Cloud and Machine Connectivity
  • OTHER
    • Upgraded Halogen Light Package
    • Amber Rotating Beacon
    • Fuel Fill Access Door
