New 14 Motor Grader for Sale

14 Motor Grader

Base Power

238 HP
Base Power

238 HP
Engine Model

Cat C13 ACERT VHP
Engine Model

Cat C13

Engine

Base Power: 238 HP
Base Power: 238 HP
Engine Model: Cat C13 ACERT VHP
Engine Model: Cat C13
Engine Model: Cat C13
Bore: 5.1 in
Bore: 5.1 in
Bore: 5.1 in
Stroke: 6.2 in
Stroke: 6.2 in
Stroke: 6.2 in
Speed at Rated Power: 1,850 rpm
Speed at Rated Power: 1,850 rpm
Emissions: Tier 4 Final/Stage IV, Tier 3 Stage IIIA equivalent or Tier 2/Stage II equivalent
Torque Rise: 41%
Maximum Torque: 1137 lbf-ft
Maximum Altitude at Full Power: 13900 ft
Maximum Altitude at Full Power: 14349 ft
Maximum Altitude at Full Power: 12049 ft
High Ambient: 550 rpm
Standard Capability: 122 ° F
Note: Net power is tested per ISO 9249, SAE J1349, and EEC 80/1269 Standards in effect at the time of manufacture.
Note: Power as declared per ISO 14396 – Rated rpm 1,850 – VHP+ = 228 kW (306 hp)
Standard: 550 rpm
Standard Capability: 122 °F
Emissions: Tier 4 Final/Stage IV, Tier 3/Stage IIIA equivalent or Tier 2/Stage II equivalent
Maximum Altitude: 13900 ft
Maximum Altitude: 12049 ft
Maximum Altitude: 14349 ft
Maximum Torque: 1137 lb/ft
Note: Net power is tested per ISO 9249, SAE J1349, and EEC 80/1269 Standards in effect at the time of manufacture.
Note: Optimized VHP Plus is standard for the 14M3.
Note: Net power advertised is the power available at rated speed of 1,850 rpm, measured at the flywheel when engine is equipped with fan, air cleaner, muffler and alternator.
Note: Power as declared per ISO 14396 – Rated rpm 1,850 – VHP+ = 228 kW (306 hp)
Torque Rise: 41%
Note: Net power advertised is the power available at rated speed of 1,850 rpm, measured at the flywheel when engine is equipped with fan, air cleaner, muffler and alternator.
Standard Capability: 122 °F
Note: Optimized VHP Plus is standard for the 14M3.
Torque Rise: 41%
Maximum Altitude: 13900 ft
Maximum Torque: 1137 lb/ft
Emissions: Tier 4 Final/Stage V, Tier 3/Stage IIIA equivalent or Tier 2/Stage II equivalent
Maximum Altitude: 14349 ft
Maximum Altitude: 12049 ft
Note: Net power is tested per ISO 9249, SAE J1349, and EEC 80/1269 Standards in effect at the time of manufacture.
Standard: 550 rpm
Note: Power as declared per ISO 14396. Rated rpm 1,850. VHP+ = 228 kW (306 hp)
Displacement: 763 in3
Displacement: 763 in³
Displacement: 763 in³
Number of Cylinders: 6
Number of Cylinders: 6
Number of Cylinders: 6
Standard: 1,600 rpm
Note: Cat engines equipped with a Selective Catalytic Reduction (SCR) system are required to use: Diesel Exhaust Fluid (DEF) which meets the requirements outlined in the International Organization for Standardization (ISO) standard 22241-1.
Note: Cat engines equipped with a Selective Catalytic Reduction (SCR) system are required to use: – Diesel Exhaust Fluid (DEF) which meets the requirements outlined in the International Organization for Standardization (ISO) standard 22241-1.
Note: Cat engines equipped with a Selective Catalytic Reduction (SCR) system are required to use: Diesel Exhaust Fluid (DEF) which meets the requirements outlined in the International Organization for Standardization (ISO) standard 22241-1.
Standard: 1,600 rpm

Weights

Operating Weight: 57250 lb
Operating Weight: 57250 lb
Gross Vehicle Weight: 50980 lb
Gross Vehicle Weight: 13994 lb
Gross Vehicle Weight: 36994 lb
Gross Vehicle Weight: 67980 lb
Gross Vehicle Weight: 21753 lb
Gross Vehicle Weight: 46224 lb
Gross Vehicle Weight: 57250 lb
Gross Vehicle Weight: 15245 lb
Gross Vehicle Weight: 42005 lb
Gross Vehicle Weight: 13994 lb
Gross Vehicle Weight: 36994 lb
Gross Vehicle Weight: 50980 lb
Gross Vehicle Weight: 15245 lb
Gross Vehicle Weight: 42005 lb
Gross Vehicle Weight: 57250 lb
Gross Vehicle Weight: 50980 lb
Gross Vehicle Weight: 13994 lb
Gross Vehicle Weight: 57250 lb
Gross Vehicle Weight: 42005 lb
Gross Vehicle Weight: 15245 lb
Gross Vehicle Weight: 36994 lb
Note: *Base operating weight calculated on standard machine configuration with 20.5 R25 tires, full fuel tank operator and ROPS cab.
Note: *Base operating weight calculated on standard machine configuration with 20.5 R25 tires, full fuel tank operator and ROPS cab.
Note: *Base operating weight calculated on standard machine configuration with 20.5 R25 tires, full fuel tank operator and ROPS cab.

Moldboard

Blade Width: 14 ft
Blade Width: 14 ft
Arc Radius: 16.3 in
Arc Radius: 16.3 in
Arc Radius: 16.3 in
Throat Clearance: 4.6 in
Throat Clearance: 4.6 in
Throat Clearance: 4.6 in
Blade Width with End Bits: 169 in
Blade Width without End Bits: 164 in
Blade Height: 24.9 in
Blade Height: 23 in
Blade Width: 169 in
Blade Width: 164 in
Blade Width: 169 in
Blade Height: 24.9 in
Blade Width: 164 in
Blade Height: 23 in

Frame

Circle: 71.7 in
Front Axle: 17.1°
Front Axle: 32°
Circle: 71.7 in
Front Axle: 32°
Front Axle: 17.1°
Circle: 71.7 in
Front Axle: 17.1°
Front Axle: 32°

Service Refill Capacities

Transmission and Differential: 23.5 gal (US)
Diesel Exhaust Fluid Tank: 5.8 gal (US)
Hydraulic System: 33 gal (US)
Circle Drive: 1.8 gal (US)
Cooling System: 15.9 gal (US)
Fuel Tank: 109.9 gal (US)

Blade Range

Maximum Depth of Cut: 23.3 in
Maximum Depth of Cut: 23.3 in
Blade Tip Range: 40°
Circle Centershift: 20.5 in
Circle Centershift: 25.6 in
Moldboard Sideshift: 31.1 in
Moldboard Sideshift: 29.1 in
Blade Tip Range: 40°
Blade Tip Range: 5°
Maximum Shoulder Reach Outside of Tires: 78.9 in
Maximum Shoulder Reach Outside of Tires: 73.6 in
Maximum Lift Above Ground: 16.5 in
Circle Centershift: 25.6 in
Maximum Lift Above Ground: 16.5 in
Circle Centershift: 20.5 in
Blade Tip Range: 5°
Maximum Shoulder Reach Outside of Tires: 78.9 in
Moldboard Sideshift: 31.1 in
Moldboard Sideshift: 29.1 in
Maximum Shoulder Reach Outside of Tires: 73.6 in
Blade Tip Range: 40°

Air Conditioning System

Air Conditioning: The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 2.0 kg (4.4 lb) of refrigerant which has a CO2 equivalent of 2.860 metric tonne (2.76 ton).
Air Conditioning: The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 2.0 kg (4.4 lb) of refrigerant which has a CO2 equivalent of 2.860 metric tonne (2.76 ton).

NOTE
- Standard and optional equipment may vary. Consult your Cat dealer for details.
OPERATOR ENVIRONMENT
- Joystick, power adjustable armrests
- Air conditioner with heater
- Centershift pin indicator
- Coat hook
- Cup holder
- Display, digital speed and gear
- Doors, left and right side with wiper
- Gauges (analog) inside cab (includes fuel, articulation, engine coolant temp, engine rpm, and hydraulic oil temp)
- Gauges, machine level
- Message display
- Joystick gear selection
- Joystick hydraulic controls for implements, steering, transmission
- Ladders, cab, left and right side
- Lights, left and right side lights
- Lights, night time cab, LED
- Meter, hour, digital
- Mirror, inside rearview, wide angle
- Power port, 12V
- Radio ready, entertainment
- ROPS cab, sound suppressed, less than 73 dB(A) ISO 6394 (70% fan speed)
- Seat, mechanical suspension, cloth
- Storage compartments
- Throttle control, electronic
POWER TRAIN
- Air cleaner, dual stage, dry-type radial seal with service indicator through messenger and dust ejector
- Articulation, automatic Return-to-Center
- Air-to-Air After Cooler (ATAAC)
- Auto Diff Lock
- Brake wear indication
- Brakes, oil disc, four-wheel, hydraulic
- Consistent power to ground
- Monitoring system
- Clutch, circle drive slip
- Differential, lock/unlock*
- Drain, engine oil, ecology
- Demand fan, hydraulic
- Engine ECO Mode
- Ether starting aid
- Fuel tank, ground level
- Fuel-water separator
- Hydraulic demand fan
- Muffler, under hood (China Nonroad Stage III and Tier 3/Stage IIIA/Tier 2/Stage II equivalent)
- Optimized VHP
- Parking brake - multi disc, sealed, oil-cooled
- Priming pump, fuel
- Sediment drain, fuel tank
- Three variations of the C13 engine. One meets Tier 4 Final/Stage V emission standards and is required for higher regulated countries. One meets Tier 3/Stage IIIA/China Nonroad Stage III standards, depending on emission standards of the specific country. One meets Tier 2/Stage II equivalent emission standards and is available for lesser or non-regulated countries, depending on standards of the specific country.
- Transmission, 8F/6R, power shift, direct drive
ELECTRICAL
- Alternator, 150 ampere, sealed
- Batteries, maintenance free, HD, 1,125 CCA
- Breaker panel
- Electrical system, 24V*
- Belt, serpentine, automatic tensioner
- Lights: reversing (LED), roof-mounted roading, stop and tail (LED)
- Product Link
- Starter, electric
- Service lights, enclosure, rear, LED
SAFETY
- Alarm, back up
- Ground level engine shutdown
- Hammer (emergency exit)
- Horn, electric
- Lockout, hydraulic implement for roading
- Operator Not Present Monitoring system
- Paint, glare reducing - top of front frame, rear enclosure and ripper cylinders
- Seat belt, retractable 76 mm (3 in)
- Secondary steering
- Windows, laminated glass: Fixed front with intermittent wiper; Side and rear wipers (3)

NOTE
- Standard and optional equipment may vary. Consult your Cat dealer for details.
OPERATOR ENVIRONMENT
- Air horn
- Heated door
- Mirrors high visibility
- Mirrors, outside heated 24V
- Mirrors, outside mounted
- Seat, heated
- Seat, heated/ventilated
- Rearview camera
- Seat belt indicator
POWER TRAIN
- Transmission, autoshift
- Engine, compression brake
TECHNOLOGY
- Cat GRADE with Cross Slope
- Stable Blade
- Advanced Control Joysticks
- Auto Articulation
GUARDS
- Debris guard
- Front axle cylinder guards
- Rear fenders
- Sound suppression, engine enclosure and transmission
- Transmission guard
- Accumulators, blade lift
- Fast fill fuel, 378.5 L/min (100 gal/min)
- Metallic DCM wear strips
ELECTRICAL
- Light, LED, warning strobe
- Lights, front headlights high
- Lights, front headlights low
- Mounting, for warning light
- Working lights halogen
- Working lights LED
SAFETY
- Additional rearview camera and monitor
- Machine security system key
OTHER ATTACHMENTS
- Moldboard, 4.9 m (16 ft)
- Heater, engine coolant, 120V
- Heater, engine coolant, 240V
- Hydraulic arrangements with additional hydraulic valves: Base +1, Base +3, Base +4, Base +5, Base +6
- Product Link satellite, cellular
- Rim, 431.8 mm x 635 mm (17 in x 25 in) MP (spare)
- Snow wing, mounting frame ready
- Fast fill
WORK TOOLS/G.E.T.
- 4.9 m (16 ft) blade with flat cutting edge 254 mm x 35 mm (10in x 1 3/8 in )
- Push block, counterweight
- Ripper, rear
- Tooth, ripper
FLUIDS
- Coolant, -51 degrees C (-60 degrees F)
