Small Wheel Loaders

926M Small Wheel Loader

  • Maximum Gross Power
    168 HP
  • Engine Model
    Cat® C7.1 ACERT™
  • Rated Net Power
    148 HP
  • Maximum Rated Gross Power
    153 HP
Engine
Maximum Gross Power
168 HP
Engine Model
Cat® C7.1 ACERT™
Rated Net Power
148 HP
Maximum Rated Gross Power
153 HP
Maximum Rated Gross Power
155 HP
Maximum Rated Gross Power
1800 r/min
Maximum Rated Gross Power
153 HP
Maximum Rated Gross Power
155 HP
Rated Net Power
163 HP
Rated Net Power
149 HP
Displacement
427 in³
Engine Model
Cat C7.1**
Maximum Gross Torque
601 ft·lbf
Maximum Gross Torque
586 ft·lbf
Maximum Net Torque
588 ft·lbf
Maximum Net Torque
573 ft·lbf
Note
Net power ratings are tested at the reference conditions for the specified standard and denote power available at the flywheel when the engine is equipped with alternator, air cleaner, emission components and fan at specified speed.
Note
No derating required up to 3000 m (10,000 ft) altitude. Auto derate protects hydraulic and transmission systems.
Rated Net Power
164 HP
Note
*Range 4 power and torque is equal to Performance Mode with Caterpillar Power by Range technology.
Note
**The Cat C7.1 engine meets Tier 4 Final/Stage V off-highway emission standards.
Rated Net Power
158 mhp
Rated Net Power
156 HP
Rated Net Power
166 mhp
Maximum Gross Power
162 mhp
Maximum Gross Power
168 HP
Maximum Gross Power
170 mhp
Maximum Gross Power
160 HP
Displacement
427 in³
Maximum Net Torque
587 ft·lbf
Maximum Net Torque
572 ft·lbf
Rated Net Power
156 HP
Bore
4 in
Bore
4 in
Stroke
5 in
Stroke
5 in
Displacement
427 in³
Rated Net Power at 1
151 hp
Maximum Gross Torque
531 lbf-ft
Maximum Net Torque
511 lbf-ft
Maximum Net Torque
517 lbf-ft
Maximum Rated Gross Power
1600 rpm
Maximum Rated Gross Power
146 hp
Maximum Rated Gross Power
148 hp
Rated Net Power at 1
141 hp
Rated Net Power at 1
142 hp
Rated Net Power at 1
144 hp
Maximum Gross Torque
531 lbf-ft
Maximum Net Torque
511 lbf-ft
Maximum Net Torque
517 lbf-ft
Emissions
Engine meets U.S. EPA Tier 4 Final/EU Stage IV emission standards.
Note
* Range 4 power and torque is equal to Performance Mode with Caterpillar Power by Range technology.
Emissions
Engine meets U.S. EPA Tier 4 Final/EU Stage IV emission standards.
Maximum Net Torque
517 lb/ft
Maximum Net Torque
517 lb/ft
Maximum Rated Gross Power
148 HP
Maximum Rated Gross Power
146 HP
Maximum Rated Gross Power
1600 r/min
Rated Net Power
142 HP
Buckets
Bucket Capacities
1.9-5.0 m3 (2.5-6.5 yd3)
Bucket Capacities
1.9-5.0 m3 (2.5-6.5 yd3)
Bucket Capacities
1.9-2.5 m³ (2.5-3.2 yd³)
Bucket Capacities
3.1-5.0 m³ (4.0-6.5 yd³)
Bucket Capacities
1.9-2.5 m3 (2.5-3.2 yd3)
Bucket Capacities
3.1-5.0 m3 (4.0-6.5 yd3)
Weights
Operating Weight
28770 lb
Operating Weight
28193 lb
Tires
Standard Size
20.5 R25, radial (L-3)
Other Choices Include
20.5 R25, radial (L-2); 20.5 R25, radial (L-5); 20.5-25 12PR (L-2); 20.5-25 12PR (L-3); 20.5-25 16PR (L-5); Flexports Gen II
Other Choices Also Include
17.5 R25, radial (L-2); 17.5 R25, radial (L-3); 17.5 R25, radial (L-5); 550/65 R25 radial (L-3); Skidder/Agriculture
Note
Other tire choices are available. Contact your Cat dealer for details.
Other Choices Include
20.5 R25, radial (L-2); 20.5 R25, radial (L-5); 20.5-25 12PR (L-2); 20.5-25 12PR (L-3); 20.5-25 16PR (L-5); 17.5 R25, radial (L-2); 17.5 R25, radial (L-3); 17.5 R25, radial (L-5); 550/65 R25 radial (L-3); Skidder/Agriculture
Note
In certain applications, the loader’s productive capabilities may exceed the tire’s tonnes-km/h (ton-mph) capabilities.
Note
Caterpillar recommends that you consult a tire supplier to evaluate all conditions before selecting a tire model.
Standard Size
20.5 R25, radial (L-3)
Axles
Front
Fixed; Locking differential (standard)
Rear
Oscillating ±11 degrees; Open differential (standard); Limited slip differential (optional)
Front
Fixed; Locking differential (standard)
Rear
Oscillating ±11 degrees; Open differential (standard); Limited slip differential (optional)
Dimensions
Width over tires
8.33
Height to Top of ROPS
10.95 ft
Height to Center of Axle
2.24 ft
Ground Clearance
1.3 ft
Overall Length
24.44 ft
Length
6.51 ft
Center Line of Front Axle
4.95 ft
Wheel Base Length
9.84 ft
Dump Clearance
9.46 ft
Bucket Pin Height at Max Lift
12.81 ft
Overall Height
16.65 ft
Reach at Max Lift and 45
3.35 ft
Rack Back Angle at Max Lift
54.0 Degrees
Dump Angle at Max Lift
50.0 Degrees
Rack Back Angle at Carry
33.0 Degrees
Carry Height
1.50 ft
Digging Depth
0.32 ft
Operating Specifications
Reach
3.35 ft
Full lift
9.46 ft
Articulation Angle
40.0 Degrees
Full Turn Tip Load
16587 lb
Cab
ROPS
SAE J1040 MAY94, ISO 3471-1994.
ROPS
ISO 3471:2008
FOPS
SAE J/ISO 3449 APR98, Level II, ISO 3449 1992 Level II.
FOPS
ISO 3449:2005 Level II
Note
Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe.
Note
The declared dynamic operator sound pressure levels per ISO 6396:2008*, when properly installed and maintained, are:
– Standard cab: 68 ±3 dB(A)
– Deluxe cab: 66 ±2 dB(A)
Note
*The measurements were conducted with the cab doors and windows closed and at 70% of the maximum engine cooling fan speed. The sound level may vary at different engine cooling fan speeds.
Steering
Steering Cylinder
2.8 in
Steering Cylinder
1.6 in
Steering Cycle Times
2.4 s
Maximum Flow
34 gal/min
Maximum Working Pressure
3500 psi
Maximum Steering Torque
37155 lbf-ft
Maximum Steering Torque
27747 lbf-ft
Steering Cycle Times
2.8 seconds
Steering Cycle Times
2.4 seconds
Maximum Flow
34 gal/min
Maximum Steering Torque
37155 ft·lbf
Maximum Steering Torque
27747 ft·lbf
Maximum Working Pressure
3500 psi
Note
Steering system uses a dedicated load sensing variable displacement pump with dual double acting cylinders.
Note
Flow values listed are for a machine running in Performance Power Mode (1,800 rpm).
Steering Cycle Times
2.4 s
Steering Cycle Times
2.8 s
Steering Cylinder
2.8 in
Steering Cylinder
1.6 in
Steering Cylinder
17.2 in
Number of Steering Wheel Turns
3.5 turns
Steering Articulation Angle
40°
Loader Hydraulic System
Maximum Flow
40 gal/min
Maximum Flow
40 gal/min
Maximum Flow
40 gal/min
Maximum Working Pressure
3771 psi
Relief Pressure
4061 psi
Relief Pressure
3771 psi
Relief Pressure
4061 psi
Lift Cylinder
4.3 in
Lift Cylinder
2.4 in
Lift Cylinder
28.7 in
Tilt Cylinder
5.1 in
Tilt Cylinder
2.8 in
Tilt Cylinder
21.9 in
Hydraulic Cycle Time
6.2 s
Hydraulic Cycle Time
1.7 s
Hydraulic Cycle Time
2.6 s
Hydraulic Cycle Time
10.5 s
Note
* 3rd and 4th function flow is fully adjustable from 20% to 100% of maximum flow through the secondary display when equipped.
Cycle Times
1.5/1.7 seconds
Cycle Times
2.6/2.6 seconds
Cycle Times
5.5/6.2 seconds
Cycle Times
9.6/10.5 seconds
Lift Cylinder
4.3 in
Lift Cylinder
2.4 in
Lift Cylinder
28.7 in
Maximum Flow
40 gal/min
Maximum Flow
40 gal/min
Maximum Flow
40 gal/min
Maximum Working Pressure
3771 psi
Note
*3rd and 4th function flow is fully adjustable from 20% to 100% of maximum flow through the secondary display, when equipped.
Note
Implement system uses a dedicated load sensing variable displacement pump with dual double acting lift cylinders and a single double acting tilt cylinder.
Note
Flow values listed are for a machine running in Performance Power Mode (1,800 rpm).
Relief Pressure
4061 psi
Relief Pressure
3771 psi
Relief Pressure
4061 psi
Tilt Cylinder
5.1 in
Tilt Cylinder
2.8 in
Tilt Cylinder
21.9 in
Hydraulic Cycle Time
9.5 s
Hydraulic Cycle Time
2.6 s
Hydraulic Cycle Time
1.5 s
Hydraulic Cycle Time
5.5 s
Maximum Flow
40 gal/min
Service Refill Capacities
Fuel Tank
51.5 gal
Cooling System
7.9 gal
Engine Crankcase
5.3 gal
Transmission
2.2 gal
Front Axles
5.5 gal
Rear Axles
5.5 gal
Hydraulic System
42.3 gal
Hydraulic Tank
23.8 gal
Diesel Exhaust Fluid
5.0 gal
Cooling System
7.9 gal (US)
Diesel Exhaust Fluid
5 gal (US)
Engine Crankcase
5.3 gal (US)
Front Axles
6.9 gal (US)
Fuel Tank
51.5 gal (US)
Hydraulic System
42.3 gal (US)
Hydraulic Tank
23.8 gal (US)
Rear Axles
6.6 gal (US)
Transmission
2.2 gal (US)
Note
DEF used in Cat SCR systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241-1.
Transmission
Forward and Reverse
1-13 km/h (0.6-8 mph)
Forward and Reverse
8 mph
Forward and Reverse
17 mph
Forward and Reverse
25 mph
Note
* Creeper control allows maximum speed range adjustability from 1 km/h (0.6 mph) to 13 km/h (8 mph) in Range 1.
Note
Factory default is 7 km/h (4.4 mph).
Forward and Reverse
1-13 km/h (0.6-8 mph)
Forward and Reverse
8 mile/h
Forward and Reverse
17 mile/h
Forward and Reverse
25 mile/h
Note
*Creeper control allows maximum speed range adjustability from 1 km/h (0.6 mph) to 13 km/h (8 mph) in Range 1 through the secondary display, when equipped. Factory default is 7 km/h (4.4 mph).
Operating Specificatons
Full Turn Tip Load
16587 lb
Power Train
Front Axle
Fixed
Front Axle
Locking differential
Rear Axle
Oscillating
Rear Axle
± 13.5 degrees
Rear Axle
± 10.5 degrees
Rear Axle
± 7 degrees
Rear Axle
Limited slip differential
Brakes
Inboard wet disc
Brakes
Spring applied hydraulically released
Brakes
Spring applied hydraulically released
Brakes
Inboard wet disc
Front Axle
Fixed
Front Axle
Locking differential
Note
Power train is governed by the Caterpillar exclusive Intelligent Power Management system to deliver peak performance and efficiency.
Note
Differential front locking axle can be engaged on the go at full torque to 10 km/h (6.2 mph) on the 926M.
Rear Axle
Oscillating
Rear Axle
± 10.5 degrees
Rear Axle
± 7 degrees
Rear Axle
Limited slip differential
Air Conditioning System
Air Conditioning
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.9 kg of refrigerant which has a CO2 equivalent of 2.717 metric tonnes.
Sound
Note
European Union Directive “2000/14/EC.”
Average Exterior Sound Pressure
101 dB(A)
Operator Sound Pressure
72 dB(A)
  • POWER TRAIN
    • Axle Duo-Cone seal guards
    • Auto idle shut down feature
    • Cat C7.1 engine
      – Power modes (Standard and Performance)
      – Power by range (High Power in Range 4)
      – Turbocharged and aftercooled
      – Diesel particulate filter (Fit for Life)
    • Coded start (requires secondary display)
    • Differential lock in front axle
    • Enclosed wet disc full hydraulic brakes
    • Hydraulically driven demand cooling fan
    • Hydrostatic transmission with electronic control
      – Operator modes (Default, TC, Hystat, and Ice)
      – Directional Shift Aggressiveness (fast, medium, slow)
      – Rimpull control, adjust wheel torque
      – Creeper control, adjust ground speed
    • Parking brake, electric
    • Single plane cooling package wide six fins per inch density
    • Oil sampling ports
    • Throttle lock and max speed limiter
  • HYDRAULICS
    • Automatic lift lower and tilt kickouts, adjustable in-cab
    • Bucket and fork modes, adjustable in-cab
    • Cylinder damping at kickout and mechanical end stops
    • Fine mode control (fast, medium, slow)
    • Hydraulic response setting (fast, medium, slow)
    • Load sensing hydraulics and steering
    • Seat-mounted hydraulic joystick controls
  • ELECTRICAL
    • Alternator, 115 amp, heavy duty
    • Batteries, 1,000 CCA (2) 24V system, disconnect switch
    • Back-up alarm
    • Emergency shutdown switch
    • Halogen work and roading lights, LED rear tail lights
    • Product Link PRO with three year subscription
    • Remote jump start post
    • Resettable main and critical function breakers
  • OPERATOR ENVIRONMENT
    • 75 mm (3 in) High-Vis retractable seat belt, with audible alarm and indicator
    • Automatic temperature control
    • Cab, pressurized
    • Camera, rearview, with dedicated display
    • External heated mirrors with lower parabolic
    • Ground level cab door release
    • Hydraulic control lockout
    • Mirror, single
    • Lunch box storage
    • Radio ready speakers
    • Rear window defrost, electric
    • Column mounted multi function control – lights, wipers, turn signal
    • Tilt and telescopic steering wheel
    • Tinted front glass
    • Wet arm wiper/washer, 2-speed and intermittent, front, lights, wipers, turn signal
    • Suspension seat, fabric
  • OTHER STANDARD EQUIPMENT
    • Large-access enclosure doors with adjustable close/open force
    • Cat optimized Z-bar linkage with parallel lift
    • Recovery hitch, with pin
    • Remote mounted lubrication points
    • Lockable compartments and enclosures
  • OPTIONAL EQUIPMENT
    • Autolube, integrated in secondary display
    • Auxiliary flow, third and fourth function
    • Differential, limited slip, rear
    • Beacon light, strobe
    • Cab, deluxe (standard in Europe)
      – Camera, rearview integrated into advanced display
      – Electrically adjustable external heated mirrors (2)
      – Secondary display to enable features and adjust parameters
      – LED interior lighting
      – Sunscreen, front and rear
      – Touchscreen secondary display
      – Ride control adjustable speed activation
      – Preventative maintenance reminders
      – Integrated help function (26 languages)
    • Camera, roof mounted, front view with separate display*
    • Cold start package
      – Ether starting aid, block heater and additional batteries, 1,000 CCA (4 total)
    • Counterweight, additional options
    • Coupler, (Fusion and ISO 23727)
    • Debris packages (low, medium, high)
    • Fenders (extended cover and full coverage)
    • Guarding packages
    • Linkage, high lift
    • Lights, auxiliary, halogen or LED with engine and DEF compartment lights
    • Payload Technology
      – Cat Production Measurement (CPM)
      – CPM Printer
    • Product Link ELITE with capabilities for software push, data logging, histogram and trend mapping
    • Radio packages
    • Rear Object Detection
    • Ride Control System, adjustable through secondary display
    • Seats
      – Deluxe seat – fully adjustable fabric air suspension seat with mid seat backrest
      – Premium seat – fully adjustable leather and fabric air suspension with high backrest and air lumbar support. Seat is heated and ventilated on bottom cushion and backrest.
    • Steering
      – Dual mode and secondary
    • Tire Pressure Monitoring (TPM)
    • *NOTE: Not all features are available in all regions.
