Electric Power

XQ35

  • Rating
    27ekW (35 kVA) Prime
  • Rating
    27 ekW (35 kVA)
  • Rating Prime
    27 ekW (35 kVA)
  • Frequency
    60 Hz
Generator
Rating
27ekW (35 kVA) Prime
Rating
27 ekW (35 kVA)
Rating Standby
30 ekW (38 kVA)
IPP Rated 60Hz
63 dB(A)
Generator Set
Rating Prime
27 ekW (35 kVA)
Frequency
60 Hz
Voltage
120 - 600V
Rating Standby
30 ekW (38 kVA)
Engine
Engine
C2.2T
Fuel
Diesel
Dimensions
Height
63.7 in
Weight
2215 lb
Length
91.3 in
Width
41.4 in
Weight
1003 lb
Weight with Lube Oil and Coolant
2215 lb
Width without Trailer
41.4 in
Height without Trailer
63.7 in
Length without Trailer
91.3 in
Fuel Consumption Prime
100
2.3 gal/hr
75
1.8 gal/hr
50
1.2 gal/hr
Fuel Consumption
100
2.3 gal/hr
75
1.8 gal/hr
50
1.2 gal/hr
100
2.6 gal/hr
75
2 gal/hr
50
1.3 gal/hr
Fuel Consumption Standby
100
2.6 gal/hr
75
2 gal/hr
50
1.3 gal/hr
Noise rating (with enclosure)
Sound Power
63 dB(A)
  • CAT C2.2T Diesel Engine
    • Heavy-duty.
      After treatment.
  • Generator
    • 1514J frame.
  • Control Panel
    • Digital EMCP4.2B set mounted controller.
  • Cat Connect remote monitoring
    • Provides package monitoring and management.
  • Cooling System
    • Package mounted radiator with vertical air discharge.
      Filled from factory.
  • Charging / Starting System
    • 12V heavy duty starting motor and charging alternator c/w battery isolator.
  • Fuel System
    • 24hr dual wall fuel tank with 3 way directional valve for external supply.
  • Air Filter
    • Cyclonic/paper with dust cup and service indicator.
  • Distribution
    • Single, robust enclosure for controls and distribution c/w 4 pole circuit breaker and safety cut off.
  • Structure
    • Heavy Duty steel base frame with integral fuel tank.
      Lifting frame and 4 point lift.
      Base frame is wider than enclosure to protect generator set during transportation.
  • Enclosure
    • Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance.
  • Exhaust
    • Integrated spark arresting silencer.
  • Lube Oil
    • On engine primary and secondary oil filters. Filled from factory.
  • General
    • Factory tested and inspected.
