Land Drilling Engines and Generator Sets

C18 ACERT Land Mechanical Drilling Engine

  • Minimum Rating
    575.0 bhp
  • Maximum Rating
    800 BHP
  • Maximum Rating
    800.0 bhp
  • Emissions
    EPA and CARB Non-Road Mobile Tier 3, EU Stage IIIA
Engine Specifications
Minimum Rating
575.0 bhp
Maximum Rating
800 BHP
Maximum Rating
800.0 bhp
Emissions
EPA and CARB Non-Road Mobile Tier 3, EU Stage IIIA
Emissions
EPA and CARB Non-Road Mobile Tier 3, EU Stage IIIA
Displacement
1100 in³
Rated Speed
2100.0 RPM
Minimum Rating
575 BHP
Bore
5.71 in
Bore
5.71 in
Stroke
7.2 in
Stroke
7.2 in
Displacement
1100.0 in3
Rated Speed
2100 r/min
Aspiration
Turbocharged-Aftercooled
Aspiration
Turbocharged-Aftercooled
Governor and Protection
ADEM A3
Engine Weight
2807.0 lb
Engine Weight
2807 lb
Oil Change Interval
250
Rotation
Counterclockwise
Oil Change Interval
250
Rotation from Flywheel End
Counterclockwise
Flywheel and Flywheel Housing
SAE No. 0 or SAE No. 1
Flywheel and Flywheel Housing
SAE No. 0 or SAE No. 1
Flywheel Teeth
136 (SAE 0), 113 (SAE 1)
Flywheel Teeth
136 (SAE 0), 113 (SAE 1)
Capacity for Liquids
Minimum Cooling System
13.2 gal (US)
Dimensions
Length
54.7 in
Length
54.7 in
Width
36.2 in
Width
36.2 in
Height
49.5 in
Height
49.5 in
  • Air Inlet System
    • Single turbocharger, mid-mounted, inlet 152.4 mm (6 in), hoseconnection
    • Dual turbocharger, front and rear inlet 127.0 mm (5 in.), hoseconnection
  • Control System
    • Electronic governing, PTO speed control
    • Programmable ratings
    • Cold mode start strategy
    • Automatic altitude compensation
    • Power compensation for fuel temperature
    • Programmable low and high idle and TEL
    • Electronic diagnostics and fault logging
    • Engine monitoring and protection system (speed, temperature,pressure)
    • J1939 Broadcast (diagnostic, engine status, and control)
  • Cooling System
    • Thermostats and housing — outlet vertical
    • Jacket water pump — gear-driven, centrifuga
    • RH front water pump inlet
    • All plugs/fittings are STOR for lines gp water
  • Exhaust System
    • Exhaust manifold — dry
    • Single turbo — front-facing turbo exhaust, full marmonconnection, maximum load 10 kg for direct connection to turbo
    • Dual turbo — exhaust elbow, dry 203 mm (8 in)
  • Flywheels and Flywheel Housings
    • See Mandatory Options
  • Fuel System
    • Electronic unit injector
    • Fuel filter, secondary, mid-mount (LH 2 micron high performance)
    • Fuel transfer pump, LH front
    • Fuel priming pump, LH mid-mount
    • Fuel sample valve, mounted on fuel filter base.
  • Lube System
    • Crankcase breather — rear valve cover
    • Oil cooler — RH (dual)
    • Oil filter — RH, LH
    • Oil pan — front sump
    • Oil dipstick — LH front
    • Oil pump
  • Mounting System
    • Front support (shipping only)
  • Power Take-Offs
    • Crankshaft pulley, 203.2 mm (8 in), 3 grooves 292.1 mm(11.5 in) 1 groove, all 15.9 mm (.63 in) width
    • Hydraulic pump drive, SAE A, 11-tooth
  • General
    • Vibration damper
    • Paint — Cat yellow
    • Lifting eyes
    • Automatic variable timing, electronic
    • Electronic installation kit 70-pin connector (connectors, pins,sockets)
  • Mandatory Options
    • Throttle position sensor
    • Single turbo only — exhaust system (front or rear)
    • Flywheel housing or rear PTO
    • Primary filter/water separator
  • Air Compressor
    • Air compressor governor
    • Expansion chambers
  • Air Inlet System
    • Air cleaners
    • Air lines
  • Charging System
    • Charging alternators
    • Alternator mountings
    • Alternator wiring
    • Circuit breakers and mountings
    • Alternator belt guard
  • Cooling System
    • Radiator
    • Fan drive with radiator packages
    • Fan height instructions
    • Vee belts
    • Aftercooler lines with Caterpillar installed radiator
    • Single turbo configuration rear-facing exhaust
    • Single turbo configuration rear-facing exhaust
    • Aftercoooler lines
    • Suction fan adapters
    • Blower fan adapter
    • Blower fan
    • Suction fan
    • Fan belt
    • Coolant level sensor
    • Dry charge coolant conditioners
  • Exhaust System
    • Turbo exhaust connection
    • Flexible fittings
    • Elbows, flange, clamp, pipes
    • Exhaust adapters
    • Manifold
    • Mufflers
  • Fuel Systems
    • Flexible fuel lines
    • Fuel filter location
    • Fuel cooler
    • Water separator
  • Instrumentation
    • Gauges and instrument panels
  • Lube System
    • Oil pans
    • Drain and cover
    • Oil level gauge
    • Remote oil filters
    • Oil filters
    • Lubricating oils
  • Mounting System
    • Structural steel base
    • Front and rear engine support
  • Power Take-Offs
    • Rear enclosed clutches
    • Hydraulic pump drives
    • Hydraulics gear pumps
    • Clutch supports
    • Crankshaft pulleys
  • Protection System
    • Air shutoff
  • Starting System
    • Air starting motors
    • Air pressure regulator
    • Air silencer
    • Start switch
    • Electric starting motors — 12V, 24V
    • Battery sets – 24V
    • Battery cable and rack
    • Starting aids
  • Transmission Arrangement
    • Transmission water lines
