Land Drilling Engines and Generator Sets

C18 ACERT Tier 4 Interim / EU Stage IIIB

  • Minimum Rating
    600.0 bhp
  • Maximum Rating
    755 BHP
  • Maximum Rating
    755.0 bhp
  • Emissions
    U.S. EPA Tier 4 Interim, EU Stage IIIB
Engine Specifications
Minimum Rating
600.0 bhp
Maximum Rating
755 BHP
Maximum Rating
755.0 bhp
Emissions
U.S. EPA Tier 4 Interim, EU Stage IIIB
Emissions
U.S. EPA Tier 4 Interim, EU Stage IIIB
Displacement
1104.5 in³
Rated Speed
1900.0 RPM
Minimum Rating
600 BHP
Bore
5.7 in
Bore
5.7 in
Stroke
7.2 in
Stroke
7.2 in
Displacement
1104.5 in3
Rated Speed
1900 r/min
Aspiration
Turbocharged-Aftercooled
Aspiration
Turbocharged-Aftercooled
Governor and Protection
ADEM A4
Engine Weight
3482.0 lb
Engine Weight
3482 lb
Rotation
Counterclockwise
Rotation from Flywheel End
Counterclockwise
Flywheel and Flywheel Housing
SAE No. 0 or SAE No. 1
Flywheel and Flywheel Housing
SAE No. 0 or SAE No. 1
Flywheel Teeth
136 (SAE 0), 113 (SAE 1)
Flywheel Teeth
136 (SAE 0), 113 (SAE 1)
Capacity for Liquids
Maximum Cooling System
7.1 gal (US)
Dimensions
Length
60.2 in
Length
60.2 in
Width
37.8 in
Width
37.8 in
Height
3482.0 in
Height
3482 in
  • Air Inlet System
    • Turbocharged Aftercooled
  • Control System
    • Electronic control system, over-foam wiring harness, automatic altitude compensation, power compensated for fuel temperature, configurable software features, engine monitoring system SAE J1939 broadcast and control, integrated Electronic Control Unit (ECU) remote fan control
  • Cooling System
    • Vertical outlet thermostat housing, centrifugal water pump, guidance on cooling system design available to ensure machine reliability
  • Exhaust System
    • Clean Emissions Module (CEM) that includes Diesel Particulate Filter (DPF), Diesel Oxidation Catalyst (DOC), and Cat Regeneration System, optional exhaust outlet
  • Flywheels and Flywheel Housing
    • SAE 0 and SAE 1 flywheel housing
  • Fuel System
    • MEUI injection; primary fuel filter, secondary fuel filters, fuel transfer pump, electronic fuel priming
  • Lube System
    • Open crankcase ventilation system, oil cooler, oil filler, oil filter, oil dipstick, oil pump (gear driven), choice of sumps (front, rear, and center)
  • Power Take Off
    • SAE B and SAE C drives available, engine power can also be taken from the front of the engine on some applications
  • General
    • Paint: Cat yellow; vibration damper; lifting eyes
