Land Electric-Drive Modules

3508B Land Electric-Drive Drilling Module

  • Minimum Rating
    835.0 ekW
  • Minimum Rating
    835 ekW
  • Maximum Rating
    835.0 ekW
  • Maximum Rating
    835 ekW
Engine Specifications
Minimum Rating
835.0 ekW
Minimum Rating
835 ekW
Maximum Rating
835.0 ekW
Maximum Rating
835 ekW
Emissions
Non-certified
Emissions
Non-certified
Engine Control and Protection
ADEM A3
Generator
SR4B
Aspiration
Turbocharged-Aftercooled
Bore
6.69 in
Stroke
7.48 in
Displacement
2111.0 in3
Fuel System
EUI
Oil Change Interval
500.0 hr
Weight
33846.0 lb
Voltage
600
Aspiration
Turbocharged-Aftercooled
Bore
6.69 in
Displacement
2111 in³
Engine Control and Protection
ADEM A3
Fuel System
EUI
Generator
SR4B
Oil Change Interval
500 h
Stroke
7.48 in
Weight
33846 lb
Dimensions
Width
91.3 in
Length
196.3 in
Height
102.2 in
Height
102.2 in
Length
196.3 in
Width
91.3 in
Capacity for Liquids
Lube Oil System
60.0 gal
Cooling System
27.0 gal
Cooling System
27 gal (US)
Lube Oil System
60 gal (US)
  • Air Inlet System
    • Corrosion-resistant aftercooler core
    • Regular duty air cleaner
    • Service indicator
  • Control System
    • ADEM A3 ECU, left-hand mounted
  • Cooling System
    • Separate-circuit aftercooled
    • Outlet controlled jacket water thermostat
    • Jacket water pump - gear driven
    • Dual outlet
    • Aftercooler water pump - gear driven
    • Aftercooler water thermostat
  • Exhaust System
    • Dry exhaust manifold
    • Dual turbochargers, water cooled bearings
    • Exhaust flexible fitting, adapters, and flanges
  • Flywheel and Housing
    • SAE No. 00 flywheel
    • SAE No. 00 flywheel housing
    • SAE standard rotation
  • Fuel System
    • Fuel filter simplex (LH) with priming pump (LH)
    • Fuel transfer pump
    • Flexible fuel lines
    • Electronic unit injectors
  • Generator
    • SR4B generator
    • Twin-bearing, close-coupled
    • Form wound, class H insulation, 80/40 temperature rise
    • Permanent magnet excitation
  • Instrumentation
    • Emergency stop button
    • Service port connector
    • Customer connection terminal blocks
    • Electronic instrument panel
    • Analog instrument gauges:
    • Digital display readouts:
  • Lubrication System
    • Crankcase breather
    • Oil cooler
    • Simplex oil filter
    • Shallow oil pan
    • Oil drain extension, 2 in NPT female connection
  • Mounting System
    • Oilfield base 7.85 m (25 ft 9 in) length. Heavy-duty land rig inner base frame — three-point mount to oilfield base
  • Power take-offs
    • Accessory drive
  • Protection System
    • Engine alarms, derate, and shutdown in abnormal operation
  • Starting System
    • Air starting motor
    • Air silencer
  • General
    • Paint - Cat yellow
    • Vibration damper and guard
    • Lifting eyes
    • Lift and cable two provisions
  • Air Inlet System
    • Heavy duty air cleaner
    • Remote air inlet adapters
  • Control System
    • Load sharing governor, 2301A
    • Load sharing module
    • Governor conversion to 0-200 mA direct rack control
  • Cooling System
    • Radiator, high gloss black conventional core radiator. Includes radiator, blower fan, fan drive, fan pulley, belt guard, radiator guard, cover, water level switch gauge, coolant level sensors
  • Exhaust System
    • Exhaust elbows
    • Exhaust mufflers
  • Fuel System
    • Primary fuel filter
  • Generator and Attachments
    • Low voltage extension box
    • Potential and current transformers
    • Air filter
    • Cable access box
    • Bearing RTDs
  • Instrumentation
    • Customer management device
    • Gauges and instrumentation panels
    • Switches and contactors
  • Lubrication System
    • Crankcase fumes disposal
    • Oil pan accessories
  • Mounting System
    • Bases
  • Power Take-off
    • Crankshaft pulley
    • Front stub shaft
    • Charging alternator
  • Protection System
    • Explosion relief valves (3)
    • Shutoffs
    • Switches and contactors
  • Starting System
    • Manual air starter
    • Air pressure regulator
  • General
    • Engine barring group
    • Jacket water heater
