Land Electric-Drive Modules
3512 Land Electric-Drive Drilling Module
-
Minimum Rating665.0 ekW
-
Minimum Rating665 ekW
-
Maximum Rating1035.0 ekW
-
Maximum Rating1035 ekW
Engine Specifications
- Minimum Rating
- 665.0 ekW
- Minimum Rating
- 665 ekW
- Maximum Rating
- 1035.0 ekW
- Maximum Rating
- 1035 ekW
- Emissions
- Non-certified
- Emissions
- Non-certified
- Engine Control and Protection
- Woodward
- Generator
- SR4B
- Aspiration
- Turbocharged-Aftercooled
- Bore
- 6.69 in
- Stroke
- 7.48 in
- Displacement
- 3158.0 in3
- Fuel System
- MUI
- Oil Change Interval
- 500.0 hr
- Weight
- 34644.0 lb
- Voltage
- 600
- Aspiration
- Turbocharged-Aftercooled
- Bore
- 6.69 in
- Displacement
- 3158 in³
- Engine Control and Protection
- Woodward
- Fuel System
- MUI
- Generator
- SR4B
- Oil Change Interval
- 500 h
- Stroke
- 7.48 in
- Weight
- 34644 lb
Dimensions
- Width
- 93.9 in
- Length
- 310.0 in
- Height
- 115.6 in
- Height
- 115.6 in
- Length
- 310 in
- Width
- 93.9 in
Capacity for Liquids
- Lube Oil System
- 84.0 gal
- Cooling System
- 41.0 gal
- Cooling System
- 41 gal (US)
- Lube Oil System
- 84 gal (US)
-
Air Inlet System
- Corrosion-resistant aftercooler core
- Regular duty air cleaner
- Service indicator
-
Control System
- Governor, Woodward EG6PC actuator — RH
- Magnetic pickup
-
Cooling System
- Thermostats and housing (dual outlet)
- Jacket water pump, gear driven
-
Exhaust System
- Dry exhaust manifold
- Exhaust flexible fitting, adapters, and flanges
-
Flywheel and Housing
- SAE No. 00 flywheel
- SAE No. 00 flywheel housing
- SAE standard rotation
-
Fuel System
- Fuel filter
- Fuel transfer pump
- Flexible fuel lines
- Fuel priming pump
-
Generator
- Oilfield generator
- Twin-bearing, close-coupled
-
Instrumentation
- Analog instrument gauges:
-
Lubrication System
- Crankcase breather
- Oil cooler
- Oil filter
- Shallow oil pan
- Oil drain extension, 2 in NPT female connection
-
Mounting System
- Oilfield base 7.85 m (25 ft 9 in) length Heavy-duty land rig inner baseframe — three-point mount to oilfield base
-
Power take-offs
- Accessory drive
- Front housing, two-sided
-
Protection System
- Hydra-mechanical shutoffs (low oil pressure, high water temperature and overspeed, air inlet shutoff). Monitoring gauge and emergency remote shutoff
- Alarm switches, low oil pressure, high water temperature (Marine Society approved) for connection to customer supplied alarm panel
- Manual shutoff control, LH
-
Starting System
- Air starting motor
- Air silencer
-
General
- Paint - Cat yellow
- Vibration damper and guard
- Lifting eyes
-
Air Inlet System
- Heavy duty air cleaner
- Remote air inlet adapters
-
Control System
- Load sharing governor, 2301A
- Load sharing module
- Governor conversion to 0-200 mA direct rack control
-
Cooling System
- Coolant level sensors
- Connections
-
Exhaust System
- Exhaust elbows
- Exhaust mufflers
-
Fuel System
- Primary fuel filter
-
Generator and Attachments
- Low voltage extension box
- Potential and current transformers
- Air filter
- Cable access box
- Bearing RTDs
-
Instrumentation
- Customer management device
- Gauges and instrumentation panels
- Switches and contactors
-
Lubrication System
- Crankcase fumes disposal
- Oil pan accessories
-
Mounting System
- Bases
-
Power Take-off
- Crankshaft pulley
- Front stub shaft
- Charging alternator
-
Protection System
- Explosion relief valves (3)
- Shutoffs
- Switches and contactors
-
Starting System
- Manual air starter
- Air pressure regulator
-
General
- Engine barring group
