Marine Generator Sets
C1.5 Marine Generator Set Engine
-
Minimum Rating10 ekW (10 kVA)
-
Minimum Rating10 ekW (10 kVA)
-
Maximum Rating13 ekW (16.5 kVA)
-
Maximum Rating13 ekW (16.5 kVA)
Generator Set Specifications
- Minimum Rating
- 10 ekW (10 kVA)
- Minimum Rating
- 10 ekW (10 kVA)
- Maximum Rating
- 13 ekW (16.5 kVA)
- Maximum Rating
- 13 ekW (16.5 kVA)
- Frequency
- 50 Hz or 60 Hz
- Frequency
- 50 Hz or 60 Hz
- Speed
- 1500 rpm (50Hz) or 1800 rpm (60 Hz)
- Speed
- 1500 rpm (50Hz) or 1800 rpm (60 Hz)
- Emissions
- 60 Hz meets EPA Tier 3*, 50 Hz meets EU 97/68EC Stage II regulations
Engine Specifications
- Engine Model
- C1.5, In-line 3, 4-Stroke-Cycle-Diesel
- Engine Model
- C1.5, In-line 3, 4-Stroke-Cycle-Diesel
- Aspiration
- Naturally Aspirated
- Aspiration
- Naturally Aspirated
- Bore
- 3.31 in
- Bore
- 3.31 in
- Stroke
- 3.5 in
- Stroke
- 3.5 in
- Displacement
- 91.0 in3
- Displacement
- 91 in³
- Governor Type
- Electrical Isochronous
- Governor Type
- Electrical Isochronous
Generator Set Configurations
- Emissions
- 60 Hz meets EPA Tier 3*, 50 Hz meets EU 97/68EC Stage II regulations
Generator Set Dimensions
- Weight
- 319 kg/703 lbs (open), 368 kg/811 lbs (enclosed)
- Weight
- 319 kg/703 lbs (open), 368 kg/811 lbs (enclosed)
- Length
- 37.4 in/962 mm (open), 40 in/1021 mm (enclosed)
- Width
- 21 in/533 mm (open), 24 in/608 mm (enclosed)
- Width
- 21 in/533 mm (open), 24 in/608 mm (enclosed)
- Height
- 27.5 in/699 mm (open), 28 in/710 mm (enclosed)
Generator Specifications
- Excitation
- AREP
- Insulation
- Class H
- Voltage Regulation
- ±0.5%
- Frame Size
- 1.5
-
Air Inlet System
- Air cleaner, single element canister type with rain cap (open generator set only)
-
Control System
- Electronic isochronous governor
-
Cooling System
- Belt-driven centrifugal jacket water pump
- gear-driven seawater pump
- heat exchanger with copper nickel tubes
- expansion tank
-
Exhaust System
- Watercooled exhaust manifold and elbow
-
Fuel System
- Fuel filter — RH or LH service
- fuel priming
- fuel transfer pump
- flexible fuel lines
-
Generator
- Single Phase
-
Lube System
- Lubricating oil
- oil filter (RH)
- dipstick (RH)
- fumes disposal (closed system)
-
Mounting System
- Anti-vibration mounts, connected to drip tray and steel base sitting on PVC foam sound-absorbent pad
-
Protection System
- Electronic automatic safety shutdown for low oil pressure, high water temperature, high exhaust (wet exhaust only) temperature, and overspeed
-
Starting System
- 12 or 24 volt electronic starting motor, 12 volt 55 amp alternator
-
General
- Single-side service (RH), decals, literature
