Marine Generator Sets
Cat C2.2 Marine Generator Set
-
Minimum Rating16 ekW (16kVA)
-
Minimum Rating16 ekW (16kVA)
-
Maximum Rating27 ekW (27 kVA)
-
Maximum Rating27 ekW (27 kVA)
Generator Set Specifications
- Minimum Rating
- 16 ekW (16kVA)
- Minimum Rating
- 16 ekW (16kVA)
- Maximum Rating
- 27 ekW (27 kVA)
- Maximum Rating
- 27 ekW (27 kVA)
- Frequency
- 50 Hz or 60 Hz
- Frequency
- 50 Hz or 60 Hz
- Speed
- 1500 rpm (50Hz) or 1800 rpm (60 Hz
- Speed
- 1500 rpm (50Hz) or 1800 rpm (60 Hz
- Emissions
- EPA Tier 3, IMO NST, EU IW
Engine Specifications
- Engine Model
- C2.2, In-line 4, 4-Stroke-Cycle Diesel
- Engine Model
- C2.2, In-line 4, 4-Stroke-Cycle Diesel
- Aspiration
- Naturally Aspirated
- Aspiration
- Naturally Aspirated
- Bore
- 3.31 in
- Bore
- 3.31 in
- Stroke
- 3.94 in
- Stroke
- 3.94 in
- Displacement
- 135.0 in3
- Displacement
- 135 in³
- Governor Type
- Electrical Ischronous
- Governor Type
- Electrical Ischronous
- Fuel System
- Fuel filter — RH or LH service, fuel priming, fuel transfer pump, flexible fuel lines
Generator Set Configurations
- Emissions
- EPA Tier 3, IMO NST, EU IW
Generator Specifications
- Excitation
- AREP
- Pitch
- 2/3 pitch
- Number of Poles
- 4
- Number of Leads
- 4
- Insulation
- Class H
- Voltage Regulation
- ±0.5%
- Frame Size
- 2.2
- IP Rating
- 23
- Wave Form Deviation
- <2%
- Voltage Regulator
- Steady State
Dimensions & Weights
- Length
- 45 in
- Length
- 46 in
- Width
- 20.5 in
- Width
- 24 in
- Height
- 32 in
- Height
- 31 in
- Minimum Approximate Weight
- 857 lb
- Maximum Approximate Weight
- 1027 lb
-
Air Inlet System
- Air cleaner, single element canister type with rain cap (open generator set only)
-
Cooling System
- Belt-driven centrifugal jacket water pump, gear-driven seawater pump, heat exchanger with copper nickel tubes, expansion tank
-
Control System
- Electronic isochronous governor
-
Exhaust System
- Watercooled exhaust manifold and elbow
-
Fuel System
- Fuel filter — RH or LH service, fuel priming, fuel transfer pump, flexible fuel lines
-
Generator
- Single-phase — brushless, shunt excited, 4-pole, 4-lead reconnectable with class H insulation, automatic voltage regulation ±0.5%, 2/3 pitch, IP23 water protection, solid state voltage regulator with integral voltage adjustment potentiometer, connection poles;
-
Lube System
- Lubricating oil, oil filter (RH), dipstick (RH), fumes disposal (closed system)
-
Mounting System
- Anti-vibration mounts, connected to drip tray and steel base sitting on PVC foam sound-absorbent pad
-
Protection System
- Electronic automatic safety shutdown for low oil pressure, high water temperature, high exhaust (wet exhaust only) temperature, and overspeed
-
Starting System
- 12 or 24 volt electronic starting motor, 12 volt 55 amp alternator
-
General
- Single-side service (RH), decals, literature
