Oil and Gas

C15 ACERT™ Tier 4 Interim Engine

  • Minimum Rating
    475 BHP
  • Maximum Rating
    580 BHP
  • Governor and Protection
    ADEM A4
  • Aspiration
    Turbocharged-Aftercooled
General Specifications
Minimum Rating
475 BHP
Maximum Rating
580 BHP
Governor and Protection
ADEM A4
Aspiration
Turbocharged-Aftercooled
Displacement
928 in³
Flywheel and Flywheel Housing
SAE No. 0 or SAE No. 1
Flywheel Teeth
136 (SAE 0), 113 (SAE 1)
Rotation from Flywheel End
Counterclockwise
Stroke
6.7 in
Bore
5.4 in
Emissions
Emissions
U.S. EPA Tier 4 Interim, EU Stage IIIB
Dimensions
Length
60.2 in.
Length
60.2 in
Width
37.8 in.
Width
37.8 in
Height
50.5 in.
Height
50.5 in
Weight
3673.0 lb
Weight
3673 lb
Capacity for Liquids
Cooling System
5 gal (US)
  • Air Inlet System
    • Turbocharged Air-to-Air Aftercooled
  • Control System
    • Electronic control system, over-foam wiring harness, automatic altitude compensation, power compensated for fuel temperature, configurable software features, engine monitoring system SAE J1939 broadcast and control, integrated Electronic Control Unit (ECU) remote fan control
  • Cooling System
    • Vertical outlet thermostat housing, centrifugal water pump, guidance on cooling system design available to ensure machine reliability
  • Exhaust System
    • Clean Emissions Module (CEM) that includes Diesel Particulate Filter (DPF), Diesel Oxidation Catalyst (DOC), and Cat Regeneration System, optional exhaust outlet
  • Flywheels and Flywheel Housing
    • SAE 0 and SAE 1 flywheel housing
  • Fuel System
    • MEUI injection; primary fuel filter, secondary fuel filters, fuel transfer pump, electronic fuel priming
  • Lube System
    • Open crankcase ventilation system, oil cooler, oil filler, oil filter, oil dipstick, oil pump (gear driven), choice of sumps (front, rear, shallow)
  • Power Take Off
    • SAE A, SAE B, SAE C drives available, engine power can also be taken from the front of the engine on some applications
  • General
    • Paint: Cat yellow; vibration damper; lifting eyes
  • Engine-Mounted Transmission Oil Cooler
    • integration with engine cooling system allows ease of installation and a tighter overall engine package
  • Engine Brakes
    • braking capabilities for mobile applications
