Oil and Gas
C7 ACERT™ Water-Cooled Manifold Engine
-
Maximum Rating275 BHP
-
Displacement442 in³
-
Minimum Rating205 BHP
-
Governor and ProtectionElectronic (ADEM™ A4)
General Specifications
- Maximum Rating
- 275 BHP
- Displacement
- 442 in³
- Minimum Rating
- 205 BHP
- Governor and Protection
- Electronic (ADEM™ A4)
- RPM
- 2200 r/min
- Aspiration
- Turbocharged-Aftercooled
- Flywheel and Flywheel Housing
- SAE 1, 2, or 3
- Flywheel Teeth
- 156 (SAE 1), 134 (SAE 2), 126 (SAE 3)
- Rotation from Flywheel End
- Counterclockwise
- Stroke
- 5 in
- Bore
- 4.3 in
Emissions
- Emissions
- EPA & CARB Non-Road Tier 3, EU Stage IIIA, EPA Marine Tier 2, IMO Tier II
Dimensions
- Length
- 43.8 in.
- Length
- 43.8 in
- Width
- 33.5 in.
- Width
- 33.5 in
- Height
- 43.8 in.
- Height
- 43.8 in
- Weight
- 1570.0 lb
- Weight
- 1570 lb
Capacity for Liquids
- Lube Oil System
- 4.8 gal
- Lube Oil System
- 4.8 gal (US)
-
Air Inlet System
- Turbocharger, separate circuit (SCAC)
- Single, right-side, center-mounted turbo with water-cooled turbine housing
- Air inlet, RH side, rear facing, 101.6 mm (4 in.) connection type
-
Control System
- Electronic governing, PTO speed control
- Programmable ratings
- Cold mode start strategy
- Automatic altitude compensation
- Fuel cooled ECU
- Power compensation for fuel temperature
- Programmable low and high idle
- Electronic diagnostics and fault logging
- Programmable monitoring system (engine speed, temperature, pressure)
- J1939 broadcast (diagnostic and engine status)
- Certified electrical control system
- Derated engine: automatic ambient temperature compensation
-
Cooling System
- Thermostats and housing, front-facing outlet — 51 mm (2.01 in) connection
- Jacket water pump — belt-driven, centrifugal
- Water pump — inlet RH front vertical inlet (pointing down) — 63 mm (2.48 in)
-
Exhaust System
- Single, right-side, center-mounted turbo with water-cooled turbine housing
- Exhaust manifold — water-cooled
- Front turbo exhaust
-
Flywheels and Flywheel Housing
- Mandatory selection of: SAE No. 1, SAE No. 2, or SAE No. 3 flywheel and housing SAE standard rotation
-
Fuel System
- HEUI fuel system
- Fuel filter — secondary, LH front (2-micron high performance)
- Fuel transfer pump — left front
- Fuel priming pump — left front
-
Lube System
- Crankcase breather — top rear
- Crankcase fumes disposal — RH
- Oil cooler — RH
- Oil filter — RH
- Oil pan — front sump, 31 L (33 qt) oil change capacity
- Oil filler — front top valve cover
- Oil level gauge — LH rear
- Engine oil pump — gear-driven
- Oil valve sampling, RH
-
Power Take-Offs
- Crankshaft drive pulley — 2 grooves, 190 mm (7.5 in) diameter, 22.3 mm (0.88 in) wide
-
General
- Vibration damper
- Lifting eyes
- Literature
- No paint
-
Mandatory Options
- Flywheel housing and flywheel
- Primary filter/water separator
- Turbo orientation
-
Air Inlet System
- Precleaner
- Air Inlet elbow
-
Cooling System
- Water outlet elbow
- Coolant conditioner
-
Emissions Certifications
- IMO certification
-
Flywheels and Flywheel Housing
- Crankshaft seal
-
Instrumentation
- Gauges and instrument panels
-
Lube System
- Oil pans
- Drain and cover
- Remote oil filters
- Lubricating oils
-
Mounting System
- Structural steel base
- Engine support -- front and rear
-
Power Take-offs
- Crankshaft pulleys
-
General
- Tool set
