Oil and Gas

C9 ACERT™ Hazardous Location Engine

  • Maximum Rating
    340 BHP
  • Displacement
    537.96 in³
  • Minimum Rating
    340 BHP
  • Governor and Protection
    Electronic (ADEM™ A4)
General Specifications
Maximum Rating
340 BHP
Displacement
537.96 in³
Minimum Rating
340 BHP
Governor and Protection
Electronic (ADEM™ A4)
RPM
2200 r/min
Aspiration
Turbocharged-Aftercooled
Flywheel and Flywheel Housing
SAE 1 or 2
Flywheel Teeth
113 (SAE 1), 134 (SAE 2)
Rotation from Flywheel End
Counterclockwise
Stroke
5.9 in
Bore
4.4 in
Emissions
Emissions
EPA and CARB Non-Road Tier 3, EU Stage IIIA, EPA Marine Tier 2, IMO Tier II
Dimensions
Length
44.4 in.
Length
44.4 in
Width
35.1 in.
Width
35.1 in
Height
42.6 in.
Height
42.6 in
Weight
2219.0 lb
Weight
2219 lb
Capacity for Liquids
Lube Oil System
8.0 gal
Lube Oil System
8 gal (US)
Cooling System
3.7 gal (US)
  • Air Inlet System
    • Turbocharger, separate circuit (SCAC) or remote (REMAC) aftercooler
    • Single, right-side, center-mounted turbo with water-cooled turbine housing
    • Air inlet 101.6 mm (4 in) connection type
  • Control System
    • Electronic governing, PTO speed control
    • Programmable ratings
    • Cold mode start strategy
    • Automatic altitude compensation
    • Fuel cooled ECU
    • Power compensation for fuel temperature
    • Programmable low and high idle
    • Electronic diagnostics and fault logging
    • Programmable monitoring system (engine speed, temperature, pressure)
    • J1939 broadcast (diagnostic and engine status)
    • Certified electrical control system (hazardous environment only)
    • Derated engine: automatic ambient temperature compensation
  • Cooling System
    • Thermostats and housing, RH forward-facing outlet — 51 mm (2.01 in) connection
    • Jacket water pump — belt-driven, centrifugal
    • Water pump — inlet RH facing downward 63 mm (2.48 in)
  • Exhaust System
    • Exhaust manifold — wet
    • Single, right-side, center-mounted turbo with water-cooled turbine housing
    • Rear facing turbo exhaust 81.8 mm (3.22 in.) connection, non V-band clamp
  • Flywheels and Flywheel Housing
    • Mandatory selection of:SAE No. 1 or SAE No. 2 flywheel and housing, SAE standard rotation
  • Fuel System
    • HEUI fuel system
    • Fuel filter — secondary, LH (2-micron high performance)
    • Fuel transfer pump — left front
    • Fuel priming pump — left front
  • Lube System
    • Crankcase breather — LH
    • Crankcase fumes disposal — with integrated service indicator, LH
    • Oil cooler — RH
    • Oil filter — RH
    • Oil pan — front sump
    • Oil filler — top mounted
    • Oil level gauge — LH side
    • Oil pump — gear-driven
    • Oil valve sampling
    • Preservation of turbocharger, flywheel, and crankcase
  • Power Take-Offs
    • Crankshaft drive pulley — 2 grooves, 190 mm (7.5 in) diameter, 22.3 mm (7/8 in) wide
  • General
    • Vibration damper
    • Lifting eyes
    • Automatic variable timing — electronic
    • Literature
  • Mandatory Options
    • Flywheel housing and flywheel
    • Primary filter/water separator
    • Turbo orientation
  • Air Inlet System
    • Air inlet elbow
    • Air shutoffs
  • Cooling System
    • Water outlet elbow
    • Coolant conditioner
  • Flywheels and Flywheel Housing
    • Crankshaft seal
  • Instrumentation
    • Gauges and instrument panels
    • Interconnect harness
  • Lube System
    • Oil pans
    • Drain and cover
    • Remote oil filters
    • Lubricating oils
  • Mounting System
    • Structural steel base
    • Engine support — front and rear
  • Power Take-Offs
    • Rear enclosed clutches
    • Hydraulic pump drives
    • Hydraulic gear pumps
    • Clutch supports
    • Crankshaft pulleys
    • Transmission Arrangement
    • General
